The ELO-231 11.2K is a fusion welding, standard response, standard coverage nozzle (available in both upright and pendent orientations) that produces a hemispherical water pattern and has been tested for high pile warehouse protection as an alternative to lower K factor (5.6 or 8.0) nozzles.
| Model | TY5111 – Upright – 3/4 in. NPT
TY5211 – Pendent – 3/4 in. NPT TY5811 – Upright – 1/2 in. NPT |
| Material | Brass,Bronze |
| K-factor, gpm/psi½ (lpm/bar½) | 11.2 gpm/psi½ (161,4 lpm/bar½) |
| Temperature Rating °F (°C)1 | 165°F (74°C)1
212°F (100°C) 286°F (141°C) |
| Thread Size | 3/4 in. NPT or ISO 7-R 3/4
1/2 in. NPT |
| Sprinkler Orientation | Upright/Pendent |
| Maximum Working Pressure, psi (bar) | 175 psi (12,1 bar) |
