Model | VK514 |
Material | Brass |
Orientation | Pendent |
K-factor, gpm/psi ½ (lpm/bar ½ ) | 28.0 (404) |
Maximum Working Pressure | 175 psi (12 bar) |
Temperature Rating °F (°C)1 | 165°F (74°C)-205°F (96°C) |
Thread Size | 1″ NPT (25 mm ) |
Application-Specific Early Suppression Fast Response (ESFR) Pendent Sprinklers
The VK514 has the capability to suppress specific high-difficulty fires. The larger K-factor allows for protection of higher-hazard commodities at higher ceiling heights and lower head pressures. The K28.0 sprinkler provides fire protection design flexibility.
Model | VK514 |
Material | Brass |
Orientation | Pendent |
K-factor, gpm/psi ½ (lpm/bar ½ ) | 28.0 (404) |
Maximum Working Pressure | 175 psi (12 bar) |
Temperature Rating °F (°C)1 | 165°F (74°C)-205°F (96°C) |
Thread Size | 1″ NPT (25 mm ) |
