Leyon FM UL STANDARD QUICK RESPONSE EXTENDED COVERAGE PENDENT SPRINKLER VK534 K11.2

The EC/QREC Pendent Sprinkler VK534 is a thermal spray style sprinkler available in a variety of finishes and temperature ratings to meet different design requirements. Extra large orifice nozzles produce the flow required to meet light and medium hazard requirements at lower pressures than standard or large orifice nozzles. Glass bulb operator and special deflector features meet Quick Response Extended Coverage standards.

Category

描述

Model VK534
Material Brass
Orientation Pendent
K-factor, gpm/psi ½ (lpm/bar ½ ) 14.0 (202)
Maximum Working Pressure 175 psi (12 bar)
Temperature Rating °F (°C)1 155°F (68°C)-200°F (93°C)
Thread Size 3/4″ NPT (20 mm )
