The Tyco SW-20 and SW-24 are 11.2K extended coverage ordinary hazard (ECOH) horizontal sidewall sprinklers (standard response, decorative glass bulb) designed for NFPA 13 ordinary hazard locations, offering large coverage areas (16×20 ft./320 sq. ft. and 16×24 ft./384 sq. ft., respectively), are suitable for wall or beam mounting where ceiling ducting is not suitable, and have an optional corrosion resistant coating.
| Model | TY5332 – SW-20 TY5337 – SW-24 |
| Material | Bronze |
| Maximum Working Pressure | 175 psi (12.1 bar) |
| Discharge Coefficient | K=11.2 GPM/psi½ (161,3 LPM/bar½) |
| Temperature Rating °F (°C)1 | 155°F (68°C)-200°F ((93°C) |
| Thread Size | 1 in. NPT or ISO 7-R 1 |
