The Tyco TY-FRB (5.6K/8.0K) is an extended coverage horizontal sidewall sprinkler (fast response or standard response) for light hazardous areas, designed for wall or beam mounting below the ceiling in spaces such as hotels, offices and churches where exposed ceiling ducting is not suitable.
| Model | TY3332 – EC HSW, 5.6K, 1/2” NPT TY4332 – EC HSW, 8.0K, 3/4” NPT |
| Material | Brass,Bronze |
| Discharge Coefficient | K=5.6 gpm/psi1/2 (80,6 lpm/bar1/2) K=8.0 gpm/psi1/2 (115,2 lpm/bar1/2) |
| Temperature Rating °F (°C)1 | 135°F (57°C)1 155°F (68°C) 175°F (79°C) |
| Thread Size | 1/2 in. NPT 3/4 in. NPT |
| Sprinkler Orientation | Upright/Pendent |
| Maximum Working Pressure, psi (bar) | 175 psi (12,1 bar) |
