描述
Model | VK536 |
Material | Brass |
Orientation | Pendent |
K-factor, gpm/psi ½ (lpm/bar ½ ) | 14.0 (202) |
Maximum Working Pressure | 175 psi (12 bar) |
Temperature Rating °F (°C)1 | 155°F (68°C)-200°F (93°C) |
Thread Size | 3/4″ NPT (20 mm) |
The Standard Response ELO Pendent Sprinkler VK536 is a thermal glass bulb spray sprinkler available in a variety of finishes and temperature ratings to meet design requirements. Special polyester and electroless nickel PTFE (ENT) coatings are available for decorative applications where color is desired. In addition, these coatings have been tested for installation in corrosive environments and are listed/approved as corrosion resistant coatings as noted in the certification chart.
Model | VK536 |
Material | Brass |
Orientation | Pendent |
K-factor, gpm/psi ½ (lpm/bar ½ ) | 14.0 (202) |
Maximum Working Pressure | 175 psi (12 bar) |
Temperature Rating °F (°C)1 | 155°F (68°C)-200°F (93°C) |
Thread Size | 3/4″ NPT (20 mm) |
